N05230-2POS для площади воздушной заслонки 1 м²

Product Overview

N05230-2POS is a direct-connected actuator SmartAct for controlling air dampers, ventilation flaps, blinds, and components of VAV devices. The model is designed to operate in ventilation and air conditioning systems where reliable positioning and easy adjustment of end positions are required.

The actuator provides precise movement and supports convenient operation thanks to the detachable connection box, mechanical stops, and the ability to select the rotation direction.

Key Benefits

• Direct connection: installation on air dampers and automation elements without complex mechanical adaptations.
• Detachable connection box: provides quick access to electrical installation and ease of maintenance.
• Selection of rotation direction: direction can be set with a switch.
• Mechanical limiters: adjustable end stops are included, and adjustment is done manually.
• Suitable for various nodes: dampers, flaps, blinds, and VAV modules.

Technical Specifications and Parameters

• Type: damper area (for damper area up to 1 m²)
• Power Supply: 230 V AC
• Network Frequency: 50 Hz
• Power Consumption: 22 VA, 2 W
• Opening/Movement Time: 110 sec
• Product Depth: 62 mm
• Operating Temperature Range: from -20 °C (−5 °F) to +60 °C (+140 °F)
• Mounting Type: square shaft of damper 6...13 mm, steps 45°
• Number of Positions: 2POS
• Body Color: White, Gray, Red

Package and Control Elements

The delivery includes components that simplify the installation and adjustment of the actuator:

• Universal shaft adapter
• Mechanical end stops (manually adjustable)
• Declutch button
• Function selection switch
• Detachable access cover
• Anti-rotation bracket
• Cable grommets
• Detachable connection box
• Cable entry: M20x1,5 / 1/2\\\" NPT

Wiring Diagram and Mechanical Adaptation

The model is designed for convenient cable entry thanks to the cable entry M20x1,5 and the option 1/2\\\" NPT. The detachable box allows for electrical installation and quick return of the cover without lengthy maintenance. Adjustable mechanical limiters help accurately set the extreme positions of the damper according to project requirements.

Where It Is Used

• Ventilation and air conditioning systems
• Control of air dampers
• Ventilation flaps and blinds
• VAV nodes and air flow distribution

Important Information for Purchasing Equipment

When purchasing equipment Resideo (Honeywell), it is recommended to contact an official dealer — LLC Promelektronika — sales@prom-elec.com. This way, you receive proper support for delivery and guaranteed availability of compatible solutions.

Delivery to Russia

Also briefly: Resideo (Honeywell) equipment is still delivered in full volume to Russia, allowing you to plan purchases for ongoing projects.

Summary

N05230-2POS SmartAct is a reliable actuator for controlling air dampers with an area of up to 1 m², with easy adjustment of end positions, the ability to select the rotation direction, and practical detachable wiring. Suitable for ventilation systems, VAV nodes, and complex automation projects.
