MV300/MV100-11/2A, стандартная версия, PN 16, NC, 230 В/50 Гц, IP65

Magnetic solenoid valve Resideo (Honeywell) MV300/MV100-11/2A — standard version, PN 16, NC, 230 V/50 Hz, IP65

MV300/MV100-11/2A — this is a magnetic solenoid valve Resideo (Honeywell), which is used as a shut-off device. The valve operates from a built-in electromagnetic drive: the voltage supply controls the position of the shutter, ensuring reliable shut-off of the water flow. The design is compact, making the model particularly convenient where installation space is limited — for example, in pipelines, ducts, and technological lines.

The device is suitable for industrial and commercial applications provided that the operating parameters specified in the manufacturer's specifications are observed.

Key advantages

• Compact design — effectively works in tight conditions (including in ducts/channels and in areas with limited space).
• High flow capacity with compact dimensions.
• NO and NC execution in the range (this model is NC, that is, normally closed).
• Integrated control circuit and thoughtful layout.
• Brass body — resistance to typical conditions of water systems.
• Threaded connections for on-site selection (within the specification).

Technical specifications

• Type of valve: magnetic solenoid (control by built-in solenoid).
• Purpose: shut-off valve (on/off).
• Controlled medium: Water.
• Nominal diameter (DN): 40 mm.
• Connection: Internal thread.
• Connection size: 1 1/2".
• Body material: Brass.
• Flow coefficient (Kvs): 64 Kvs.

Electrical and operational parameters

• Execution by voltage: 230 V / 50 Hz.
• Degree of protection: IP65.
• Nominal pressure: PN 16.
• Type of operation by shutter state: NC (normally closed).

Where it is used

Valves MV300/MV100-11/2A are used where quick and reliable shut-off/on of the water flow is required. Typical scenarios:

• technological circuits with water supply control;
• engineering systems of buildings and commercial infrastructure facilities;
• industrial installations where compactness and stable operation of shut-off valves are important;
• areas with limited installation space.

How to choose the right valve

To ensure the equipment operates correctly, consider the parameters of the network and medium when selecting:

• the suitable type of shutter (NO/NC) for your control scheme;
• compliance with pressure (here — PN 16);
• the diameter of the pipeline and size of the threaded connection (in this model — 1 1/2", DN 40);
• the type of medium (in the card — water);
• power supply and execution by protection class (230 V/50 Hz, IP65).

Why it is important to buy Resideo (Honeywell) from an official dealer

To receive Resideo (Honeywell) equipment with correct delivery and support for original products, it is recommended to purchase Resideo (Honeywell) equipment from the official dealer LLC Promelektronika: sales@prom-elec.com.

Delivery to Russia

It is also important to note that Resideo (Honeywell) equipment is still fully delivered to Russia, which helps plan purchases and maintenance of engineering systems without unnecessary delays.

Order MV300/MV100-11/2A and ensure reliable control of water supply in your system — taking into account the required DN, type of connection, and electrical parameters.
