D06FI-1A PN16, DN25, нержавеющая сталь, прозрачная колба фильтра, комплект подключения

Pressure reducer D06FI-1A from Resideo (Honeywell) is a high-quality solution for protecting your plumbing system from excess pressure and stabilizing the output pressure at a set level. This device is ideal for residential, commercial, and industrial water supply systems, where reliable protection of equipment and maintenance of stable operating parameters are required.

Main characteristics and advantages:

• Reliable protection: Prevents damage to pipelines, faucets, household appliances, and other components of water supply caused by excessive pressure in the main pipeline.
• Pressure stabilization: Ensures constant output pressure within the specified range, regardless of fluctuations in input pressure, guaranteeing stable operation of connected devices.
• Adjustment range: The output pressure can be easily adjusted within 1.5 to 6 bar using a convenient adjustment handle.
• Pressure indication: The built-in scale allows for visual control of the set output pressure.
• Hygiene: The adjusting spring is isolated from contact with drinking water, meeting high hygiene standards.
• Integrated filter: A fine filter mesh with a cell of 0.16 mm protects the system from mechanical impurities, extending the equipment's lifespan.
• Durability: The valve body is made of high-quality stainless steel, and the seat is made of EPDM, ensuring resistance to corrosion and wear.
• Compliance with standards: The product meets the requirements of international standards, including DVGW and WRAS (up to 23 °C), as well as BS EN 1567. The materials meet the requirements of UBA and are certified by ACS.
• Versatility: Suitable for use with drinking water at temperatures up to 30 °C.

Technical details:

• Model: D06FI-1A
• Nominal pressure (PN): 16 bar
• Nominal diameter (DN): DN 25
• Body material: Stainless steel
• Seat material: EPDM
• Working medium: Drinking water
• Maximum medium temperature: 30 °C
• Maximum input pressure: 16 bar (with transparent filter bowl)
• Output pressure range: 1.5 - 6 bar
• Flow coefficient (Kvs): 5.8
• Maximum flow coefficient: 5.8
• Filter mesh size: 0.16 mm
• Minimum pressure drop: 1 bar
• Port diameter: 1 inch
• Connection type: Connection set
• Height of the product: 111 mm
• Approvals and standards: DVGW, WRAS (up to 23 °C)
