Honeywell S7830A1021/U

Honeywell · Артикул: S7830A1021/U

Расширительный сигнализатор на основе микропроцессора для поддержки ретрансляционных модулей серии 7800 для первоначального оповещения, последовательности, системы или самодиагностики и устранения неполадок. Двадцать шесть светодиодов состояния. Светодиодная панель на передней панели предназначена для индикации потока линейного напряжения через ряд ограничений, элементов управления и блокировок. Выбираемый текущий и первый светодиодный дисплей. Двадцать один контролируемый контакт. Доступ для проверки внешнего электрического напряжения. Product Specifications Application Expanded Annunciator Dimensions (in.) 5 in. wide x 5 in. high x 5 1/4 in. deep with Q7800A Subbase x 6 3/32 in. deep with Q7800B Subbase Dimensions (mm) 127 mm wide x 127 mm high x 133 mm deep with Q7800A Subbase x 155 mm deep with Q7800B Subbase Weight (lb) 1 lb 6 oz Weight (kg) 0.62 kg Frequency 50 Hz; 60 Hz (±10%) Approvals, Underwriters Laboratories Inc. Component Recognized, File No. MH17367; Guide No. MJAT. Approvals, Canadian Standards Association Certified, File No. LR95329. Customer Special Cleaver Brooks Voltage 120 Vac (+10, -15%) Shipping and Storage Temperature Range (F) -40 F to +140 F Shipping and Storage Temperature Range (C) -40 C to +60 C Approvals, Federal Communications Commission FCC Part 15, Class B, Emissions. Required Components 7800 Series Relay Modules and Q7800A, B Subbases Vibration 0.5 G environment

Характеристики

0

{"name":"Application","value":"Expanded Annunciator","scope":"product_row","group":"Параметры исполнения"}

1

{"name":"Dimensions (in.)","value":"5 in. wide x 5 in. high x 5 1/4 in. deep with Q7800A Subbase x 6 3/32 in. deep with Q7800B Subbase","scope":"product_row","group":"Параметры исполнения"}

2

{"name":"Dimensions (mm)","value":"127 mm wide x 127 mm high x 133 mm deep with Q7800A Subbase x 155 mm deep with Q7800B Subbase","scope":"product_row","group":"Параметры исполнения"}

3

{"name":"Weight (lb)","value":"1 lb 6 oz","scope":"product_row","group":"Параметры исполнения"}

4

{"name":"Weight (kg)","value":"0.62 kg","scope":"product_row","group":"Параметры исполнения"}

5

{"name":"Frequency","value":"50 Hz; 60 Hz (±10%)","scope":"product_row","group":"Параметры исполнения"}

6

{"name":"Approvals, Underwriters Laboratories Inc.","value":"Component Recognized, File No. MH17367; Guide No. MJAT.","scope":"product_row","group":"Параметры исполнения"}

7

{"name":"Approvals, Canadian Standards Association","value":"Certified, File No. LR95329.","scope":"product_row","group":"Параметры исполнения"}

8

{"name":"Customer Special","value":"Cleaver Brooks","scope":"product_row","group":"Параметры исполнения"}

9

{"name":"Voltage","value":"120 Vac (+10, -15%)","scope":"product_row","group":"Параметры исполнения"}

10

{"name":"Shipping and Storage Temperature Range (F)","value":"-40 F to +140 F","scope":"product_row","group":"Параметры исполнения"}

11

{"name":"Shipping and Storage Temperature Range (C)","value":"-40 C to +60 C","scope":"product_row","group":"Параметры исполнения"}

12

{"name":"Approvals, Federal Communications Commission","value":"FCC Part 15, Class B, Emissions.","scope":"product_row","group":"Параметры исполнения"}

13

{"name":"Required Components","value":"7800 Series Relay Modules and Q7800A, B Subbases","scope":"product_row","group":"Параметры исполнения"}

14

{"name":"Vibration","value":"0.5 G environment","scope":"product_row","group":"Параметры исполнения"}
